3.2V 3.7V Lithium 18650 Lifepo4 Battery BMS Protection Circuit Board 1S 5A

Name: 32V 37V Lithium 18650 Lifepo4 Battery BMS Protection Circuit Board 1S 5A
Brand: ENERKEY
Price: 1.80 USD

Wholesale 3.2V 3.7V Lithium 18650 Lifepo4 Battery BMS Protection Circuit Board 1S 5A from china suppliers

Place of Origin : Guangdong, China

Brand Name : ENERKEY

Model Number : JW-B1S5A-012

Packaging Details : Carton

Supply Ability : 50000 Piece/Pieces per Month

MOQ : 5 pieces

Price : $1.80/pieces 5-199 pieces

Certification : ISO9001/ROHS/CE

Application : LED lights, Emergency lights, Digital Equipment

Type : PCM

Features : 1S Battery 5A Current

Mounting Type : built-in

Size / Dimension : L28*W5*T2.5 mm

Description : Battery power supply Smart BMS

Base Material : FR-4

Board Thickness : 1.0mm

Surface Finishing : HASL Lead Free

Solder mask color : Green.White.Black.Red.Yellow.Blue.Purple.Matte Green. Matte Black

Voltage : 3.7V

Current : 5A

Suitable for battery string : 1S

Battery type : Lifepo4 / Li-ion Battery

Protection function : Overcharge ,Overdischarge ,Overcurrent ,Short-circuit

Other functions : Thermistor temperature protection,Balance

Contact Now

3.7V 3.2V Lithium LiFePO4 18650 Battery Pack Protection Circuit Board 5A Charger BMS

Product Description

Electric Parameter

PCM Specifications For 3.2V (1S) LiFePO4 Battery Packs

Model:JW-B1S5A-012

NO.

Project

Min.

Typ.

Max.

Unit

voltage

Charging voltage

3.65

Balance voltage for single cell

Current

Balance current for single cell

Current consumption

Maximal continuous charging current

Maximal continuous discharging current

Over charge protection

Overcharge detection voltage for single cell

3.725

3.75

3.775

Overcharge detection delay time

0.5

Overcharge release voltage for single cell

3.55

3.60

3.65

Over discharge protection

Overdischarge detection voltage for single cell

2.05

2.10

2.15

Overdischarge detection delay time

100

Overdischarge release voltage for single cell

2.25

2.30

2.35

Overcurrent protection

Over current detection voltage

0.185

0.2

0.225

Over current detection current

Detection delay time

Release condition

Cut load,Automatic recovery

Short protection

Detection condition

Exterior short circuit

Detection delay time

200

500

μS

Release condition

Cut load,Auto recovery

Resistance

Protection circuitry (MOSFET)

mΩ

Temperature

Operating Temperature Range

-40

℃

Storage Temperature Range

-40

1255

℃

Product Use Tutorial

3.2V 3.7V Lithium 18650 Lifepo4 Battery BMS Protection Circuit Board 1S 5A
